Arduino Sound Sensor Module / Sound Sensor with arduino Code

Made by karimmufte / Animals / Art / Clocks / Communication / Drones / Environmental Sensing

About the project

All resource are given here free. Its easy to understand.

Project info

Difficulty: Easy

Estimated time: 1 hour

License: Creative Commons Attribution CC BY version 4.0 or later (CC BY 4+)

Items used in this project

Hardware components

Genuino Uno Rev3

x 1

Story

Arduino is an open-source electronics platform based on easy-to-use hardware and software. Arduino boards are able to read inputs - light on a sensor, a finger on a button, or a Twitter message - and turn it into an output - activating a motor, turning on an LED, publishing something online. You can tell your board what to do by sending a set of instructions to the microcontroller on the board. To do so you use the Arduino programming language (based on Wiring), and the Arduino Software (IDE), based on Processing.Over the years Arduino has been the brain of thousands of projects, from everyday objects to complex scientific instruments. A worldwide community of makers - students, hobbyists, artists, programmers, and professionals - has gathered around this open-source platform, their contributions have added up to an incredible amount of accessible knowledge that can be of great help to novices and experts alike.

Schematics, diagrams and documents


CAD, enclosures and custom parts


Go to download

Code

Arduino Code

https://plus.google.com/u/0/+MahamudulKarimKhondaker/posts/NNAjthiHg5i

#include <LiquidCrystal.h>
const int rs = 12, en = 11, d4 = 5, d5 = 4, d6 = 3, d7 = 2;
LiquidCrystal lcd(rs, en, d4, d5, d6, d7);
void setup(){ lcd.begin(16, 2);
  Serial.begin(9600); // open serial port, set the baud rate to 9600 bps
}
void loop(){int val;
      val=analogRead(0);   //connect mic sensor to Analog 0
      Serial.print("Sound=");
      Serial.println(val,DEC);//print the sound value to serial
      lcd.setCursor(0, 0);
lcd.print("Sound=");
lcd.print(val);
lcd.print("   ");
delay(1000);}
